Thick Film

We offer one of the broadest lines of SMA Coaxial Circulators / Duplexers in various packages sizes and frequency bands.  Reliability, price and maufacturability are optimized at the design stage and proven through temperature cycling and automated final test. Our standard SMA Coaxial Circulators are supplied with SMA Female connectors. Male connectors, phase matching, counter clockwise rotation, higher shielding along with required intermodulation specifications can be provided upon request.

ProductPower (W)VDCMin ResistanceMax ResistancePDF
HV6011500250K4,000MPDF
HV6522500300K10,000MPDF
HV7035000500K15,000MPDF
HV8047500750K20,000MPDF
HV100515000750K30,000MPDF
HV120620000750K50,000MPDF
